2026 Chevrolet Trax near Lakeville, MN
The 2026 Chevrolet Trax is a compact vehicle engineered with a turbocharged three-cylinder engine, a six-speed automatic transmission, and a chassis configuration designed to support responsive handling and practical everyday functionality. The model combines defined powertrain specifications with a spacious interior layout and a comprehensive suite of standard safety technologies. Chevrolet also introduced new exterior color choices for selected trims for the 2026 model year. In addition to its engine and drivetrain components, the 2026 Chevrolet Trax features packaged passenger accommodations, flexible cargo capacity, and a range of driver-assistance systems.
Engine Performance and Fuel Efficiency
The 2026 Chevrolet Trax uses an ECOTEC 1.2L Turbo I-3 engine that combines turbocharging with direct fuel injection and a dual overhead camshaft valvetrain. The engine incorporates an aluminum high-pressure die-cast block and a die-cast aluminum cylinder head, contributing to its overall construction. Bore and stroke measurements are 2.95 inches by 3.54 inches, equivalent to 75 mm by 90 mm. This powerplant produces 137 horsepower at 5,000 rpm and generates 162 lb-ft of torque at 2,500 rpm.
ECOTEC 1.2L Turbo I-3 Engine
The ECOTEC 1.2L Turbo I-3 provides the 2026 Chevrolet Trax with a compact engine architecture supported by direct fuel delivery. The DOHC configuration manages valve operation and forms an integral part of the engine’s design. Peak torque becomes available at 2,500 rpm, while maximum horsepower is achieved at 5,000 rpm. The combination of these output figures establishes the operating characteristics of the powertrain throughout the engine speed range. EPA-certified fuel economy ratings for the 2026 Chevrolet Trax are 28 mpg in city driving and 32 mpg on the highway.
Disclaimer: *EPA-estimated 28 MPG city/32 highway/30 combined.
Transmission and Drivetrain
The drivetrain of the 2026 Chevrolet Trax pairs the turbocharged engine with a Hydra-Matic 6T40 six-speed automatic transmission. This transmission provides six forward gears and a reverse gear, allowing the engine to operate through a wide range of vehicle speeds. A final drive ratio of 3.53 complements the transmission ratios and forms part of the overall driveline specification. The gear arrangement provides distinct ratio spacing from first gear through sixth gear.
Hydra-Matic Six-Speed Automatic Transmission
The Hydra-Matic 6T40 automatic transmission uses a first gear ratio of 4.58 to provide initial acceleration characteristics. Second gear is rated at 2.96, followed by a third gear ratio of 1.91 and a fourth gear ratio of 1.44. Fifth gear uses a direct 1.00 ratio, while sixth gear is configured with a 0.74 ratio. Reverse gear is rated at 2.94, and the final drive ratio measures 3.53. These values establish the complete gear ratio structure used by the 2026 Chevrolet Trax.
Chassis Components and Handling Systems
The 2026 Chevrolet Trax uses suspension and steering components designed to provide structural support and controlled vehicle behavior. A MacPherson® strut front suspension with coil-over springs works together with a direct-acting stabilizer bar. The rear suspension uses a compound crank torsion beam design combined with coil springs and twin-tube shock absorbers. Steering assistance comes from a column-mounted electric power-assisted rack-and-pinion system. Four-wheel disc brakes provide stopping capability for the vehicle.
Suspension Design
The front suspension system employs a MacPherson® strut layout with coil-over springs positioned to support wheel movement and vehicle stability. A direct-acting stabilizer bar forms part of the front suspension assembly and contributes to overall chassis operation. At the rear, the compound crank torsion beam design incorporates coil springs and twin-tube shock absorbers. This suspension arrangement defines the mechanical structure used on the rear axle.
Steering and Braking Systems
The steering system uses a column-mounted electric power-assisted rack-and-pinion configuration. This design integrates electric assistance into the steering mechanism and forms part of the vehicle’s chassis system. Braking performance is supported by four-wheel disc brakes located at each wheel position. The steering and braking systems work with the suspension components to establish the overall chassis configuration.
Exterior Dimensions and Wheel Configurations
The dimensions of the 2026 Chevrolet Trax establish its exterior proportions and contribute to its overall packaging. The wheelbase measures 106.3 inches, or 2,700 mm, while the overall length is 178.6 inches, or 4,537 mm. Overall width measures 71.7 inches without mirrors, and overall height is 61.4 inches. Front track width is 61.4 inches, and rear track width is 62.3 inches. Ground clearance is rated at 7.3 inches, equivalent to 186 mm.
Wheel Availability
Wheel specifications vary across the trim lineup of the 2026 Chevrolet Trax. LS models use 17-inch steel wheels, while LT models feature 17-inch aluminum wheels. The 1RS and ACTIV trims receive 18-inch aluminum wheels. The 2RS trim is equipped with 19-inch aluminum wheels.
Exterior Color Updates
Chevrolet introduced two new exterior color options for the 2026 model year. White Sands is available exclusively on ACTIV and RS models. Apex Red is offered on LS, LT, 1RS, and 2RS trims. These additions expand the available exterior color selections for the 2026 Chevrolet Trax. Color availability varies according to trim designation.
Interior Dimensions and Cargo Capacity
The interior dimensions of the 2026 Chevrolet Trax support passenger accommodations in both seating rows. Front headroom measures 39.6 inches, while rear headroom measures 38.1 inches. Front legroom is rated at 41.9 inches, and rear legroom measures 38.7 inches. Shoulder room measures 55.7 inches in the front and 54.3 inches in the rear. Front hip room measures 52.1 inches, while rear hip room is rated at 45.3 inches.
Passenger Space
The EPA passenger volume of the 2026 Chevrolet Trax measures 99.8 cubic feet, or 2,826 liters. These dimensions define the amount of interior space available for occupants. The measurements cover seating accommodations across both rows. Front and rear dimensions provide distinct allowances for headroom, legroom, shoulder room, and hip room.
Cargo Storage Capacity
Cargo volume behind the rear seat measures 25.6 cubic feet, or 725 liters. Folding the rear seat expands cargo capacity to 54.1 cubic feet, or 1,532 liters. Cargo and load capacity remain subject to weight and distribution limitations. The expanded cargo area increases the amount of available storage space when the rear seat is folded.
Safety and Driver Assistance Technologies
The 2026 Chevrolet Trax incorporates standard occupant protection systems together with multiple driver-assistance technologies. Six airbags are included as standard equipment and consist of frontal and knee airbags for the driver and front passenger. Seat-mounted side-impact airbags and roof-rail-mounted head-curtain airbags protect front and rear outboard seating positions. A Tire Pressure Monitor System with tire fill alert is also standard, excluding the spare tire if equipped. A Rear Vision Camera forms part of the standard safety equipment package.
Chevy Safety Assist
Chevy Safety Assist is standard on the 2026 Chevrolet Trax and includes several driver-assistance technologies. The system package incorporates Automatic Emergency Braking, Front Pedestrian Braking, Lane Keep Assist with Lane Departure Warning, Forward Collision Alert, IntelliBeam® auto high-beams, and Following Distance Indicator. These technologies are intended to support driver awareness and vehicle operation. Feature performance can be influenced by visibility, weather conditions, and road conditions. Drivers remain responsible for maintaining attention to traffic and surrounding conditions during vehicle operation.
Available Driver Assistance Features
Additional driver-assistance technologies are available for the 2026 Chevrolet Trax. Available systems include Adaptive Cruise Control, Side Blind Zone Alert with Lane Change Alert, Rear Cross Traffic Alert, and Rear Park Assist. These features supplement the standard safety equipment and expand the range of available driver-support technologies. Their operation depends on environmental and driving conditions. They are intended to assist the driver and do not replace attentive vehicle operation.
Schedule a Test Ride Today
Our team invites drivers to experience the engineering and equipment found throughout the 2026 Chevrolet Trax at Sota Chevrolet near Lakeville, MN. We encourage customers to schedule a test drive to explore the turbocharged engine, six-speed automatic transmission, and suspension design firsthand. During your visit, our staff can demonstrate the interior space, cargo flexibility, and available driver-assistance technologies. A test drive also provides an opportunity to evaluate comfort, handling characteristics, and the operation of key safety features. We look forward to helping you examine the functional attributes that define the 2026 Chevrolet Trax.
