2026 Chevrolet Trailblazer near Lakeville, MN
The 2026 Chevrolet Trailblazer is engineered as a compact sport utility vehicle with a focus on efficiency, structural balance, and integrated safety systems. It offers two turbocharged engine configurations, multiple drivetrain layouts, and a combination of mechanical and electronic systems designed to support consistent operation. The model continues with its established architecture while introducing updated exterior color options and additional equipment for 2026.
Turbocharged Engine Architecture and Output
The 2026 Chevrolet Trailblazer uses two ECOTEC turbocharged inline three-cylinder engines. The base engine is a 1.2-liter unit constructed with an aluminum block and aluminum cylinder head. It uses a dual overhead camshaft configuration and direct fuel injection. This engine produces 137 horsepower at 5,000 rpm and 162 lb.-ft. of torque at 2,500 rpm. The bore measures 2.95 inches, and the stroke measures 3.54 inches.
The available 1.3-liter ECOTEC turbocharged engine also uses aluminum construction with a dual overhead camshaft design and direct injection. It produces 155 horsepower at 5,600 rpm and 174 lb.-ft. of torque at 1,600 rpm. The bore measures 3.11 inches, and the stroke measures 3.58 inches. The lower torque peak of the 1.3-liter engine allows earlier delivery of torque, which supports consistent acceleration from lower engine speeds.
Transmission Systems and Gear Ratios
Front-wheel-drive 2026 Chevrolet Trailblazer models equipped with either engine use a continuously variable transmission. This transmission operates with a variator ratio spread of 7.0:1. The underdrive ratio is 2.621:1, and the overdrive ratio is 0.374:1. The reverse ratio is 0.67:1, and the final drive ratio is 5.45:1. This system allows the engine to operate within an efficient range during acceleration and cruising.
All-wheel-drive models equipped with the 1.3-liter engine use a 9-speed automatic transmission. The gear ratios are structured to support both low-speed control and highway efficiency. First gear is 4.69:1, second gear is 3.31:1, third gear is 3.01:1, fourth gear is 2.45:1, fifth gear is 1.92:1, sixth gear is 1.45:1, seventh gear is 1.00:1, eighth gear is 0.75:1, and ninth gear is 0.62:1. Reverse gear is 2.96:1. The final drive ratio for this transmission is 3.17:1.
Fuel Economy Metrics and Tank Capacity
Fuel economy varies based on engine selection and drivetrain configuration. The 1.3-liter engine with front-wheel drive is rated at 29 miles per gallon in the city and 33 miles per gallon on the highway. The all-wheel-drive configuration with the 1.3-liter engine is rated at 26 miles per gallon in the city and 29 miles per gallon on the highway. Fuel economy figures for the 1.2-liter engine were not available in the provided specifications.
The 2026 Chevrolet Trailblazer uses a fuel tank with an approximate capacity of 13.2 gallons. This capacity supports the vehicle’s compact design while maintaining a balance between driving range and weight.
Disclaimer: *EPA-estimated 29 MPG city/33 highway (1.3L FWD).
Suspension Design, Steering Calibration, and Braking System
The front suspension uses a MacPherson® strut configuration. The rear suspension uses a compound crank design, with a Watts link included on all-wheel-drive models. This setup provides structural support and consistent wheel control across varying road conditions.
The steering system is an electric power-assisted rack-and-pinion design. It provides a turning circle of 36.8 feet, which supports maneuverability in confined spaces.
The braking system consists of electric four-wheel disc brakes with Duralife™ rotors. The system includes anti-lock braking functionality, brake drying capability, and brake life monitoring. The front brake rotors measure 11.80 inches in diameter and 1.03 inches in thickness. The rear rotors measure 10.40 inches in diameter and 0.40 inches in thickness.
Wheel Dimensions and Tire Specifications
Wheel sizes vary depending on trim level. LS, LT, and ACTIV models are equipped with 17-inch aluminum wheels. LT models also offer 18-inch aluminum wheels, while RS models use 19-inch aluminum wheels.
Tire configurations are matched to wheel size and intended use. LS and LT models use 225 by 60 R17 all-season tires. ACTIV models use 225 by 60 R17 sport terrain tires. LT models equipped with 18-inch wheels use 225 by 55 R18 all-season tires. RS models use 245 by 45 R19 all-season tires.
Exterior Dimensions and Structural Proportions
The 2026 Chevrolet Trailblazer has a wheelbase of 103.9 inches. The overall length is 173.5 inches, and the overall width is 71.2 inches. Vehicle height varies by trim and drivetrain. Front-wheel-drive LS, LT, and ACTIV models measure 65.2 inches in height. Front-wheel-drive RS models measure 65.3 inches. All-wheel-drive models measure 65.7 inches in height.
The front track measures 61.2 inches, and the rear track measures 61.3 inches. These dimensions contribute to the vehicle’s structural balance and compact positioning within the segment.
Interior Measurements and Passenger Space
The 2026 Chevrolet Trailblazer provides a total passenger volume of 98.2 cubic feet. Front headroom measures 40 inches without a sunroof and 38.3 inches with a sunroof. Rear headroom measures 38.4 inches without a sunroof and 36.8 inches with a sunroof.
Front legroom measures 40.9 inches, while rear legroom measures 39.4 inches. Front shoulder room measures 55.4 inches, and rear shoulder room measures 53.8 inches. Front hip room measures 52.3 inches, and rear hip room measures 50.39 inches. These measurements indicate a balanced cabin layout with consistent spacing for front and rear occupants.
Cargo Capacity and Load Handling
Cargo capacity behind the rear seat measures 25.3 cubic feet. When the rear seat is folded, the maximum cargo volume increases to 54.4 cubic feet. This configuration allows the vehicle to accommodate larger items while maintaining a compact external size.
The 2026 Chevrolet Trailblazer has a trailering capacity of 1,000 pounds when equipped with an accessory hitch. Load distribution and total weight affect towing capacity, and the presence of passengers or cargo may reduce the available limit.
Weight Distribution and Base Curb Figures
The base curb weight of the 1.2-liter front-wheel-drive model is 3,029 pounds. The 1.3-liter front-wheel-drive model has a curb weight of 3,095 pounds. The all-wheel-drive model equipped with the 1.3-liter engine has a curb weight of 3,252 pounds. These figures reflect the added weight of drivetrain components and structural reinforcements in all-wheel-drive configurations.
Integrated Safety Systems and Standard Driver Assistance
The 2026 Chevrolet Trailblazer includes a comprehensive set of airbags. These include driver and front passenger frontal airbags, knee airbags, seat-mounted side-impact airbags, and roof rail-mounted head-curtain airbags for outboard seating positions. The system also includes a passenger sensing feature.
A tire pressure monitoring system is standard and includes a tire fill alert function. The vehicle is equipped with an HD Vision Camera to support rear visibility.
The Chevy Safety Assist package is standard on all models. This package includes Automatic Emergency Braking, Front Pedestrian Braking, Lane Keep Assist with Lane Departure Warning, Following Distance Indicator, Forward Collision Alert, and IntelliBeam® automatic high beams. These systems provide driver awareness support across multiple driving scenarios.
Expanded Driver Assistance Packages and Control Systems
Additional driver assistance features are available through optional packages. The Driver Confidence and Cruise Package available on LS includes cruise control, Lane Change Alert with Side Blind Zone Alert, Rear Cross Traffic Alert, and Rear Park Assist.
LT, ACTIV, and RS models offer Adaptive Cruise Control as an available feature. These trims also offer a Driver Confidence Package that includes Lane Change Alert with Side Blind Zone Alert, Rear Cross Traffic Alert, and Rear Park Assist. These systems extend driver support for lane monitoring, parking, and controlled cruising conditions.
2026 Model Year Enhancements and Equipment Updates
The 2026 Chevrolet Trailblazer introduces two new exterior color options. These include White Sands and Apex Red. These additions expand the available exterior finishes without altering the vehicle’s mechanical structure.
The model also includes a tire inflator kit as part of its updated equipment list. This addition supports roadside tire maintenance and reduces reliance on a traditional spare tire in certain configurations.
Visit Sota Chevrolet for a Test Ride
Sota Chevrolet near Lakeville, MN, provides access to the 2026 Chevrolet Trailblazer for direct evaluation of its engine performance, drivetrain response, and safety technologies. Scheduling a test drive allows you to examine the 1.3-liter turbocharged engine output, the operation of the CVT or 9-speed automatic transmission, and the function of the standard driver assistance systems. You can assess steering response, braking feel, and cabin dimensions under controlled conditions. The available configurations allow you to compare front-wheel-drive and all-wheel-drive setups based on your requirements. Contact our dealership to arrange a test drive and review the specifications in detail through direct experience.
